AKUVOX – R20K Slim SIP Intercom with Keypad and RF card reader

Akuvox Intercom

SKU AKV-R20K Category Tag

Key Features

SIP Intercom with one Button (Video & Card reader)

Body material: Zinc alloy

Camera: 2M pixels, automatic lighting

Camera viewing angle: 110°(H) / 58°(V)

RF Card Reader 13.56MHZ&125KHZ Card reader

Output Relay: 1 output relays for door opener

Water-proof & Dust-proof: IP65

Installation: Surface Mount model

Two-way audio communication over IP networks with Echo Cancel

SKU: AKV-R20K

Specifications

PoE

True

Ethernet

RJ45, 10/100Mbps adaptive

IP Rating

IP65

Vandal Rating

IK07(V5.0)

Power Consumption

5.58W

Power Input

12V DC connector

Video Compression

H.264

Audio Compression

G.711a, G.711μ,G.722

Storage

128MB

Image Sensor

1/2.8”, CMOS

Angle Of View

110°(H) / 58°(V)

Bidirectional Talk

True

Network Protocol

IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

Operating Humidity

10~90%

Operating System

Linux

Support Standard Poe

True

Ip rating

IP65

Image sensor

1/2.8”, CMOS

Installation

Flush-mounted & Wall-mounted

Warranty

2 years

Power consumption

5.58W

Operating humidity

10~90%

Operating system

Linux

Poe

True

Vandal rating

IK07(V5.0)

Video compression

H.264

Power input

12V DC Connector

Working temperature

'-30°C ~ 60°C

Material

Aluminum Alloy

Brand

Akuvox

Support standard poe

True

Bidirectional talk

True

Angle of view

110°(H) / 58°(V)

Audio compression

G.711a, G.711μ,G.722

Network protocol

IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

Working Temperature

-30°C ~ +60°C

Day/Night

False

Camera

False

Casing

False

LCD Screen

False

Downloads

Akuvox R20K Data Sheet
