Milesight – MS-C5375-PD/W, AI Weatherproof Mini Dome Network Camera in WHITE

SKU MS-C5375-PD/W Categories ,

Key Features

Download Brochure

AI Weatherproof Mini Dome Network Camera

  • Support PoE; Builtin Microphone; SD card, up to 256G; 3Axis Design
  • Support H.265+/H.265/H.264+/H.264
  • AI Based Video Content Analysis

Optional

  • Lens 4mm/6mm
  • Black Housing
  • High Frame Rate (R Series: 2MP@60fps)
  • Junction Box (Need to be assembled before delivery)

Specifications

Brand
IR Illuminators

Color: [email protected]/W: 0Lux with IR on
Network Access Control

IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.16x, QoS, IGMP, ICMP, SSL
Network Storage

Y
ONVIF

Y
Protocols

IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.16x, QoS, IGMP, ICMP, SSL
ROI

Y
S/N Ratio

>55dB
Scheduled Task

Y
Image Sensor

1/2.8″ Progressive Scan CMOS
Smart IR

Y
Sub Stream

Y
Third Stream

Y
Smart Record

Y
Minimum Illumination

Color: [email protected]/W: 0Lux with IR on
User Authentication

Y
White Balance

Y
Working Temprature

-40℃~60℃
Max. Resolution

2592×1944
Shutter Time

1/100000s~1s
Field of View

H105°/D131°/V78°(2.8mm)H86°/D108°/V63°(4mm)H52°/D63°/V40°(6mm)
Video Motion Detection

Y
Working Humidity

0~90%(Non-condensing)
Main Stream

Y
Max. Frame Rate

2592×1955
Day/Night

True
IR Distance

Up to 25m
Alarm Input

Y
Connection Type

PoE
IP Rating

IP67
Megapixels

5MP
Vandal Rating

IK10
Management Software

SmartTools；CMS;M-sight pro APP
Power Input

PoE (802.3af) / DC 12V±10%
Video Compression

H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
Network Interface

Y
Storage

Support microSD/SDHC/SDXC Card Local Storage, up to 271G
Audio Output

Y
Audio Compression

G.711/AAC/G.722/G.726
Iris Type

Auto
Audio Input

Y
Audio Interface

Y
Basic Event Detection

Y
Digital Zoom

Y
Event Action

Y
Event Detection

Y
Event Trigger

Y
Focus Mode

Y
image enhancement

Y
Image Settings

Y
Brand

Milesight
Alarm Output

Y
Mobile Compatible

False
Alarm Linkage

False
Explosion Proof

False
Removable IR-Cut Filter

False
Software Development Kit

False
Water and Dust Resistant

False
